Cartoning Machine DZH-120F

Automatic Cartoning Machine

Cartoning Machine DZH-120F

Description
DZH-120F series Cartoning are intermittent motion cartoning machines capable of packing reverse type tuck in cartons for various industries like Pharma, Food, Cosmetics, etc.

Manufactured with cGMP norms, having branded components for electric and pneumatic functions. Simple and steady design confirms the machine performance and stability. With various arrangements of feeders it can auto feed Tubes, Pouch, Food Tray, bottle, Bearings, Electrical components and many more articles. Machines can be linked with upstream and downstream machines in line.

Technical Specification :

Machine Dimension Specification :
L = 3600 W = 1300 H = 1600 Weight = 1700Kgs
Working Area :
L = 5500 W = 2500 H = 2500 -
Carton Specifications :
Maximum L = 250 W = 130 H = 90
Minimum L = 75 W = 50 H = 20
GSM 300 - 350
Utility Required :
Air Pressure 6 ~ 7 bar
Air Consumption 300 ~ 330 Lt/min
Electrical Specification :
Connected Load 1.5 kW
Rated Voltage 415 + 10% V
Frequency 50 + 2% Hz
Connection 3 wire
Speed :
Standard Machine Cycles 30 - 80 Cycles per min*
*Carton speed depend upon product size & shape, packing material & feeding arrangement.
